| Type | SMB4 - D - 27 | SMB4 - 35 | SMB4 - 35 | SMB4 - 45 |
|---|---|---|---|---|
| No. of station | 27 | 35 | 35 | 45 |
| Type of tooling | D | DB | B | BB |
| Output tablets / hour * (Single Layer) | 58,320 to 129,000 | 75,600 to 168,000 | 75,600 to 168,000 | 97,600 to 216,000 |
| Maximum operating pressure (main) | 10 Tons | 10 Tons. | 6.5 Tons | 6.5 Tons |
| Maximum tablet diameter | 23 mm (25 mm on Demand) | 19 mm (21 X 9mm Caplet) | 16 mm | 11.1 mm |
| Maximum depth of fill | 20 mm | 20 mm | 17.5 mm | 17.5 mm |
| Upper punch penetration | 1.5 to 8 mm | |||
| Main electric motor | 3.70 kW / 5hp, 1440 RPM 415 V, 50 Hz., 3Phase | |||
| Overall dimensions (cm) | 105 x 106 x 181 H | |||
| Case Dimension (cm) | 130 x 131 x 200 H | |||
| Net weight | 1490 kg | |||
| Grass Weight | 1680 kg | |||
* Depending upon the Tooling Size & Shape, material characteristics and also ambient condition. NOTE: DUE TO CONTINIOUS IMPROVEMENTS IN THE MACHINERIES, SPECIFICATION/SHAPE OF THE MACHINERIES IS SUBJECT TO CHANGE WITHOUT ANY PRIOR NOTICE.
